共挤包覆结构的20%短切碳纤维增强ABS 3D打印材料。
产品简介
FusCoating™ NexABS-CF20是一款具有双层包覆结构的20%碳纤维增强ABS 3D打印线材。线材外层为高粘接强度的纯ABS树脂，线材内芯为20%短切碳纤维增强的ABS树脂。FusCoating™ NexABS-CF20 3D打印包覆线材利用了高分子熔体在挤出过程中一般为层流运动的特性，线材在通过打印机喷头后仍能保持稳定的双层包覆结构，打印时的Z轴层间方向可以始终保持为外层的纯树脂之间粘接，大幅度提高了纤维增强类FDM材料的Z轴层间强度。
物性表
测试项目 Property | 测试方法 Testing method | 典型值 Typical value |
密度 Density | ISO 1183 | 1.09 g/cm³ |
熔融指数 Melt index | 250℃, 2.16kg | 5.5 g/10min |
热变形温度 Determination of temperature | ISO 75: Method A | 83 °C (1.80MPa) |
ISO 75: Method B | 90 °C (0.45MPa) | |
拉伸强度（X-Y） Tensile strength(X-Y) | ISO 527 | 47.86±2.32 Mpa |
拉伸模量（X-Y） Young’s modulus(X-Y) | 4606.28±192.38 Mpa | |
断裂伸长率（X-Y） Elongation at break (X-Y) | 1.48±0.11 % | |
弯曲强度（X-Y） Bending strength (X-Y) | ISO 178
| 80.21±0.55 Mpa |
弯曲模量 （X-Y） Bending modulus (X-Y) | 4365.29±153.79 Mpa | |
缺口冲击强度 （X-Y） Charpy impact strength （X-Y） | ISO 179 | 8.12±0.78 KJ/㎡ |
拉伸强度 (Z) Tensile strength (Z) | ISO 527 | 28.21±0.35 MPa |
拉伸模量（Z） Young’s modulus (Z) | 2713.50±88.38 MPa | |
断裂伸长率（Z） Elongation at break (Z) | 1.81±0.16 % |
试样打印参数：喷嘴温度250℃，底板加热100℃，打印速度50mm/s，填充率100%，填充角度±45°
Specimens printed under the following conditions: Nozzle temp 250℃, Bed temp 100℃, Print speed 50mm/s, Infill 100%, Infill angle ±45°
建议打印参数
喷头温度 Nozzle Temperature | 250-270°C |
建议喷嘴大小 Recommended Nozzle Diameter | 0.4-1.0 mm |
建议底板材质 Recommended build surface treatment | PEI底板或者涂抹PVP固体胶 PEI or Coating with PVP glue |
底板温度 Build plate temperature | 100-110°C |
Raft间距 Raft separation distance | 0.18-0.2 mm |
冷却风扇 Cooling fan speed | 0%-20% |
打印速度 Print speed | 30-120 mm/s |
回抽距离 Retraction distance | 1-3 mm |
回抽速度 Retraction speed | 1800-3600 mm/min |
建议支撑材料 Recommended support material | FusFree™ S-Multi Quick-Remove Support Material |
其他建议： 1. FusCoating™ NexABS-CF20对比普通ABS纤维增强材料拥有更高的纤维含量，这种技术进一步提高了ABS材料的抗翘曲能力和刚性，因此可以适当降低环境温度以达到节能的目的。 2. 长期打开包装后的线材，如打印过程中发现气泡、拉丝等打印质量下降问题，请将线材置于60-70℃条件下干燥4-6h。 3. 建议在打印ABS材料时将打印机放置在通风环境中。 4. FusCoating™ NexABS-CF20基于熔体稳定流动时处于层流状态的机理，材料在喷嘴挤出的细丝结构中依然能保持双层结构。但当打印速度过高时，熔体流动状态将变得不稳定，耗材在喷嘴挤出后的细丝将会破坏双层结构，最终导致打印件的表面质量变得粗糙。当出现此现象时建议提高打印温度或降低挤出速度。 5. 建议使用Phaetus硬化钢及以上等级耐磨喷头，可以有效提高打印质量，建议加热块厚度不小12mm。
Additional Suggestions： 1. FusCoating™ NexABS-CF20 has a higher fiber content compared with ordinary ABS-GF/CF. This technology further improves the warping resistance and rigidity of ABS materials, so the chamber temperature can be properly reduced to achieve energy saving. 2. If the filament has been opened for a long time and problems such as air bubbles and stringing appear during the printing process, please dry the filament at 60-70°C for 4-6 hours. 3. It is recommended to place the printer in a well-ventilated environment when printing with ABS material. 4. FusCoating™ NexABS-CF25 can maintain a core-skin structure when extruded from the nozzle. It is based on the mechanism that the melt polymer is in a laminar state when it flows stably, However, when the printing speed is too high, the melt flow state will become unstable, and the filaments extruded from the nozzle will no longer have the skin-core structure anymore, which can cause the rough surface of the printed part. When this phenomenon occurs, it is recommended to increase the printing temperature or reduce the extrusion speed. 5. It is recommended to use Phaetus hardened steel nozzles or nozzles with greater abrasion resistance, which can effectively improve the printing quality. The thickness of the heating block is recommended to be no less than 12mm. | |
挤出压力与打印流量速度测试
测试参数：12mm长度铜制加热块，BMG挤出机，Phaetus硬化钢喷头，喷嘴大小0.4mm，层高0.2mm。
Test parameters: 12mm length brass heat block, BMG extruder, Phaetus Hardened Steel Nozzle, Nozzle size 0.4mm, Layer Height 0.2mm.
