未增强特种高温尼龙3D打印材料。
产品简介
FusForceTM PAHT专为FDM 3D打印工艺开发，基材选用高温尼龙原料，具有低吸湿，高强度，高耐磨性，耐化学性优异和高耐热性的特点。打印过程中尺寸稳定性好，无翘边无收缩现象，并且可以与FusFreeTM S-PAHT易剥离支撑材料配合使用，解决复杂模型支撑面成型效果差的难题。
物性表
测试项目 Property | 测试方法 Test Method | 典型值 Typical value | |
密度 Density | ISO 1183 | 1.21 g/cm³ | |
吸湿率 Water absorption | ISO 62: Method 1 | 2.59 % | |
熔点 Melting Temperature | ISO 11357 | 231°C | |
熔融指数 Melt index | 280°C, 2.16kg | 9.4 g/10min | |
| 干燥状态 Dry Condition | 饱和吸湿状态 Saturation hygroscopic conditions | |
热变形温度 Determination of temperature | ISO 75: Method A | 72.5°C (1.80MPa) | 48°C (1.80MPa) |
ISO 75: Method B | 79.6°C (0.45MPa) | 60.0°C (0.45MPa) | |
拉伸强度（X-Y） Tensile strength(X-Y) | ISO 527 | 69.29±1.17 MPa | 57.63±2.14 MPa |
拉伸模量（X-Y） Young’s modulus(X-Y) | 3329.72±235.60 MPa | 2896.78±152.93 MPa | |
断裂伸长率（X-Y） Elongation at break (X-Y) | 9.77±1.68 % | > 50% | |
弯曲强度（X-Y） Bending strength (X-Y) | ISO 178 | 112.64±1.60 MPa | 82.23±7.36 MPa |
弯曲模量 （X-Y） Bending modulus (X-Y) | 3202.24±115.78 MPa | 2408.32±274.58 MPa | |
缺口冲击强度 （X-Y） Charpy impact strength （X-Y） | ISO 179 | 9.74±0.84 KJ/㎡ | 13.10±1.70 KJ/㎡ |
单层拉伸强度（Z） Single layer Adhesion tensile strength（Z） | Custom Method: Nozzle diameter 0.6mm Layer Height 0.3mm Volumetric Speed 10.8mm³/s | 50.03±2.30 MPa | / |
试样打印参数：喷嘴温度280°C，底板加热80°C，打印速度45mm/s，填充率100%，填充角度±45°
Specimens printed under the following conditions: Nozzle temp 280°C, Bed temp 80°C, Print speed 45mm/s, Infill 100%, Infill angle ±45°
建议打印参数
喷头温度 Nozzle Temperature | 260-280°C |
建议喷嘴大小 Recommended Nozzle Diameter | 0.4-1.0mm |
建议底板材质 Recommended build surface treatment | PEI底板或者涂抹PVP固体胶 PEI or Coating with PVP glue |
底板温度 Build plate temperature | 70-80°C |
Raft间距 Raft separation distance | 0.12-0.16 mm |
冷却风扇 Cooling fan speed | 20%-60% |
打印速度 Print speed | 30-120 mm/s |
回抽距离 Retraction distance | 1-3 mm |
回抽速度 Retraction speed | 1800-3600 mm/min |
建议支撑材料 Recommended support material | FusFreeTM S-PAHT Quick-Remove Support |
其他建议： 1. 尼龙材料非常容易吸收环境内的水分，吸湿后打印会出现拉丝，挤出有气泡等现象，降低打印质量。建议您打开FusForceTM PAHT真空铝箔袋包装后立即将线材放入干燥盒内（湿度控制在15%以下）进行打印。不用的线材请放回原包装铝箔袋内密封保存。 2. 材料受潮后会出现打印拉丝增多，挤出有气泡，打印表面质量粗糙等现象。请将线材放入80-100°C烘箱内干燥4-6h，即可恢复FusForceTM PAHT的打印质量。 3. 建议选用Phaetus硬化钢及以上等级喷嘴，可以有效提高打印质量，建议加热块厚度不小于12mm。
Additional suggestion 1. Nylon material is very easy to absorb moisture within the environment, and printing after absorbing moisture will result ozzing, extruding with bubbles and rough surface appearance, thus reducing print quality. It is recommended that put the filament into a dry box (humidity below 15%) immediately after opening the FusForceTM PAHT vacuum foil bag for printing. Please put the unused filament back into the original aluminum foil bag for sealed storage. 2. After the material is damp, there will be more printing ozzing, bubbles extruded and rough printing surface. Please dry the filament in an oven at 80-100°C for 4-6h to restore the printing quality of FusForceTM PAHT. 3. It is recommended to use hardened steel and above grade nozzles made by Phaetus, which can effectively improve the print quality. Besides, it is recommended that the thickness of the heating block is longer 12mm. | |
挤出压力与打印体积速度测试
挤出压力与打印体积速度测试
测试参数：20mm长度铜制加热块，BMG挤出机，Phaetus硬化钢喷头，喷嘴大小0.4mm，层高0.2mm。
Test parameters: 20mm length brass heat block, BMG extruder, Phaetus Hardened Steel Nozzle, Nozzle size 0.4mm, Layer Height 0.2mm.
