净重

1 Kg / 2.5Kg / 3Kg

线径

1.75 mm / 2.85 mm

颜色

本色 / 白色 / 黑色 /红色 / 橙色 / 灰色 / 黄色 / 紫色 / 绿色 / 军绿色 / 棕色 / 肤色 / Silver

TDS技术文件

低气味ABS 3D打印材料

产品简介

FusFun™ ABS是一款专门为3D打印开发的ABS类耗材,与同类产品相比具有更低的气味性和更强的机械性能。

FusFun™ ABS选用的主要原料是一款由连续本体法合成的ABS树脂,得益于这种先进的生产工艺,生产过程中使用的溶剂和单体在最终ABS成品中的残留量极低,因此耗材在打印过程中的具有较低的气味性。

FusFun™ ABS同时具有较低的水分敏感性,耗材开封后无需特殊的防潮措施,线材暴露在空气中打印也不会出现明显的拉丝现象。并且可以与FusFree S-Multi易剥离支撑材料配合使用,解决复杂模型支撑面成型效果差的难题。

物性表

测试项目

Property

测试方法

Test Method

典型值

Typical value

密度

Density

ISO 1183

1.05 g/cm³

玻璃化转变温度

Glass transition temperature

ISO 11357

101°C

熔融指数

Melt index

250°C,2.16kg

7.8 g/10min

维卡软化点

Vicat softening temperature

ISO 306

103°C

热变形温度

Determination of temperature

ISO 75:Method A

ISO 75:Method B

86°C (1.8MPa)

92°C (0.45MPa)

拉伸屈服强度

Tensile yield strength

(X-Y)

ISO 527

38.96±0.33 MPa

拉伸屈服伸长率

Tensile Yield elongation

(X-Y)

2.32±0.02 %

拉伸模量

Young’s Modulus

(X-Y)

2384.22±20.0 MPa

拉伸断裂强度

Tensile breaking strength

(X-Y)

33.36±0.53 MPa

断裂伸长率

Elongation at break

(X-Y)

5.77±0.84 %

拉伸强度

Tensile breaking strength

(Z)

ISO 527

(无保温环境/开放式打印机)

(Without chamber temp)

26.16±1.73 MPa

拉伸模量

Young’s Modulus

(Z)

1967.57±119.93 MPa

断裂伸长率

Elongation at break

(Z)

1.62±0.14 %

拉伸强度

Tensile breaking strength

(Z)

ISO 527

(密闭打印机,腔体温度约55℃)

(Chamber Temp: 55℃)

32.25±0.72 MPa

拉伸模量

Young’s Modulus

(Z)

2201.74±74.91 MPa

断裂伸长率

Elongation at break

(Z)

2.70±0.59 %

弯曲强度

Bending strength

(X-Y)

ISO 178

67.81±0.54 MPa

弯曲模量

Bending Modulus

(X-Y)

2400±79.69 MPa

缺口冲击强度

Charpy impact strength

(X-Y)

ISO 179

20.03±1.32 KJ/㎡



试样打印参数:喷嘴温度250℃,底板加热100℃,打印速度50mm/s,填充率100%,填充角度±45°

Specimens printed under the following conditions: Nozzle size 0.4mm,Nozzle temp 250°C, Bed temp 100°C, Print speed 50mm/s, Infill 100%, Infill angle ±45°

建议打印参数

喷头温度

Nozzle Temperature

240-260°C

建议喷嘴大小

Recommended Nozzle Diameter

≥0.2 mm

建议底板材质

Recommended build surface treatment

Glass、PEI Film or PC Film

底板温度

Build plate temperature

100-110°C

Raft间距

Raft separation distance

0.16-0.18 mm

冷却风扇

Cooling fan speed

Off-30 %

打印速度

Print speed

30-120 mm/s

回抽距离

Retraction distance

1-5 mm

回抽速度

Retraction speed

1800-3600 mm/min

建议支撑材料

Recommended Support Material

FusFree™ S-Multi Quick-Remove Support

其他建议

1. ABS材料相比PLA,PETG等材料在打印过程中需要有较高的环境温度来帮助释放零件成型过程中的残余应力,在打印过程中请将打印机保持封闭状态,可以有效避免打印零件出现翘曲和开裂现象。如果设备具有加热腔功能,建议将加热腔温度设置在60-80°C之间。

2. 长期打开包装后的ABS线材,如打印过程中发现打印质量下降,请将线材置于70-80℃条件下干燥4-6h。

3. 虽然FusFun™ ABS与同类产品相比气味更小,但仍然建议在打印时将打印机放置在通风环境中。



Additional Suggestions:

1. Compared with PLA, PETG and other materials, ABS materials need a higher chamber temperature to help release the residual stress during the printing process. Please keep the printer chamber closed during the printing process. It can effectively avoid printed parts from warping and cracking. If the device has a heated chamber, it is recommended to set the temperature of heated chamber between 60-80°C.

2. If the ABS filament has been unpacked for a long time and the printing quality starts to degrade during the printing process, please dry the filament at 70-80°C for 4-6 hours before printing.

3. Although FusFunTM ABS has much less odor compared with similar products, it is still recommended to place the printer in a well-ventilated area during printing.



挤出压力与打印流量速度测试

测试参数:12mm长度铜制加热块,BMG挤出机,Phaetus硬化钢喷头,喷嘴大小0.4mm,层高0.2mm。

Test parameters: 12mm length brass heat block, BMG extruder, Phaetus Hardened Steel Nozzle, Nozzle size 0.4mm, Layer Height 0.2mm.
